Metallization Ceramics
Mo Mn Ceramic Feedthrough Ceramic Vacuum Electrodes
The Ceramic Surfaces for Brazing, the surface must be metallized.
Compare to Glass seal, Ceramic seal has exceptional resistance to thermal and mechanical shock as well as corrosion. While it requires more complex manufacturing processes and sophisticated engineering, the price is obviously higher.
The Ceramic Surfaces for Brazing, the surface must be metallized.
Compare to Glass seal, Ceramic seal has exceptional resistance to thermal and mechanical shock as well as corrosion. While it requires more complex manufacturing processes and sophisticated engineering, the price is obviously higher.
Advantages of Ceramic-to-Metal Seals
* More solid, durable hermetic seal and better electrical insulation
* Used for more harsh conditions, such as high and low (cryogenic) temperature, corrosive, high pressure, and high vacuum environments
* High mechanical strength, less fracture when applied to high vibration and high g-load conditions
* Shows strong bond and an excellent seal with metals and alloys, such as copper and Cu alloys (CuNi) and to nickel and Ni alloys.
* More solid, durable hermetic seal and better electrical insulation
* Used for more harsh conditions, such as high and low (cryogenic) temperature, corrosive, high pressure, and high vacuum environments
* High mechanical strength, less fracture when applied to high vibration and high g-load conditions
* Shows strong bond and an excellent seal with metals and alloys, such as copper and Cu alloys (CuNi) and to nickel and Ni alloys.
|
Material
|
Alumina/BeO/AlN
|
|
Coating Layer
|
Mo/MnThickness:8-30μm
|
|
Plated Layer
|
Nickel, Copper, Gold, etc. Thickness: 2-9μm
|
|
Treatment
|
Glazed, polishing
|
|
Dimension
|
Customized
|
|
Joining types
|
|
|
Ceramic + Mo/Mn Metallized + plating Ni
|
|
|
Ceramic + Mo/Mn Metallized + plating Ag
|
|
|
Ceramic + Mo/Mn Metallized + plating Au
|
|
|
Ceramic + printing Ag
|
|
Application
> Feedthrough
> Metal/alloy ceramic metallized
> Screen Printing
> Roll Printing
> Hand Painting
> Air Brush Spraying
> Immersion
> Centrifugal Coating
> Needle Painting
